Solar ray collecting device
14 May 1986
Text
Page 1bibliographic recordscan →
Patentamt a i s c h e sPatent Office
J E u r o p European Publication number: 0 1 28 395 Office europeen des brevets A3
EUROPEAN PATENT APPLICATION
Application number: 84105694.8 Int. CI.4: F 24 J 3 / 0 2
Priority: 03.06.83 JP 99978/83 Applicant: Mori, Kei
Date of publication of application:
19.12.84 Bulletin 84/51 Inventor: Mori, Kei
Date of deferred publication of search report: 14.05.86 Setagaya-ku Tokyo(JP) Designated Contracting States: Representative: Patentanwalte Grunecker, Dr. CH DE FR GB LI NL Kinkeldey, Dr. Stockmair, Dr. Schumann, Jakob, Dr. Bezold, Meister, Hilgers, Dr. Meyer-Plath
Maximiiianstrasse 58
Solar ray collecting device.
A solar ray collecting device is comprised of a supporting base plate on which a large number of hexagonal recesses are provided and a large number of optical systems are arranged on each of said recesses. Each of said optical systems is made up of a hexagonal focusing lense of a dimension that is approximately the same as the hexagonal recesses and of a head-cut hexagonal pyramid which extends downward from the light collecting lense as an upper surface of said recess. An optical conductor which is a light-receiving surface is provided on the focus of said light collecting lense. Furthermore, the upper internal circumferential surface of the side wall forming said recess is so formed that it may be able to move freely on the surface of said hexagonal pyramid.
